Mobile Solar Power Station
Plug - and - play
|
Solar power station uses customized containers compliant with maritime transport standards as the carrier, equipped with maintenance-free foldable brackets, guide rail and support systems, inverters, energy storage batteries and other modules inside. It has the advantagesof low cost, integration, mobility, fast and easy deployment, scalability, etc., and is widely suitable for areas with power shortages or excessively high electricity costs. It is widely used in scenarios suchas mining, agricultural irrigation, remote islands, oil and gas mining areas, construction sites, post-war reconstruction, etc. |
 |
 Configuration |
|
|
 Core advantages |
Sustainable benefit: Stable power supply more than 20years, reduce electricity costs, eliminate grid dependence All-in-one integrated: Integrate PV & energy storage in standard containers, convenient for transport and loading Flexible extension: Equipped with high efficiency PV, extensible for different needs Efficient power generation: 20GP/20HQ power generation up to 92kWh/107kWh, can store 241kWh electricity Easier install: Standard rail auxiliary, finishin stallation within 60 minutes by 4 person Compatible with genset: Genset input port, offer uninterrupted power |
|
 |
 Parameters |
Parallel containers of different capacities, low cost operation is simple and flexible, and can be combined into a variety of configuration schemes to meet more power and energy needs. | |
|
Container Type |
8FT | 10FT | 20GP | 20HC | 40GP | 40HC |
| Model | IMP08-18K20 | IMP10-30K40 | IMP20-92K240 | IMP20H-107K240 | IMP40-170K240 | IMP40H-210K430 |
| Generating power | 18kW | 30kW | 92kW | 107kW | 170kW | 210kW |
| Energy | 20kWh | 40kWh | 241kWh | 241kWh | 241kWh | 430kWh |
| Expanded dimension | 36000*3000*1000mm | 54000*3000*1000mm | 100000*6100*1100mm | 113000*6100*1100mm | 100000*12200*1100mm | 113000*12240*1100mm |
| Transport dimension | 3000*2200*2300mm | 3000*2438*2591mm | 6058*2438*2591mm | 6058*2440*2896mm | 12200*2438*2591mm | 12200*2438*2896mm |
| Curb weight | 4800kg | 7500kg | 12750kg | 12700kg | 25000kg | 28000kg |
| Cooling method | 风冷 | 风冷 | 风冷 | 风冷 | 风冷 | 风冷 |
| IP rating | IP54 | IP54 | IP54 | IP54 | IP54 | IP54 |
| Corrosion protect grade | C3H | C3H | C3H | C3H | C3H | C3H |
| Operating temperature | Charge/discharge：0℃~+55℃/-20℃~+55℃ | |||||
| Communication method | USB/RS485/4G/WIFI(Optional) | |||||
